Steering motor adjustment problem.
Hi there. New to this group hope all of you are doing good. I'll introduce myself in the right location after this post. I have a problem with the steering wheel motors..they both seem to be stuck. I tried lubricants and help the threaded shaft to rotate but not budging.... I still am working to try the VCDS route to test the system with the Ross tech but wondered if any of this was familiar to anyone? Thank you.
Bib https://youtu.be/o7YTXoffXtE?si=mtI7JdCsLDFpT4Ev
|
|
#2
12th June 2025, 12:26 PM
|
||||
|
||||
|
I've never had the problem, but have you tried a bit of gentle persuasion on the steering wheel at the same time you're pushing the button? i.e. Push the button to move the steering wheel out whilst pulling the steering wheel gently.
__________________
2001 A8 D2 FL 3.7 Q - LPG Conversion, Engine: AKC, Gearbox:FBB, Colour:LY5X Aqua Blue pearl effect, Interior:WJ light beige/dark beige valcona leather with burr walnut inserts My DIY jobs - Replaced alarm horn, Replaced Coolant Temp sensor, Updated RNS-D firmware, Installed Reversing Camera and Digital TV, Dashcam Installation, Retrofitted Rear Blinds, Auto-Dimming Rear View Mirror, Chrome Boot Struts Sold!  2008 S8 D3 5.2 V10 - Engine: BSM, Gearbox:KLW, Colour:LY7F Suzuka Grey Pearl Effect, Interior:Black/Black with Silver/Black valcona leather with carbon atlas inserts, Bang & Olufsen, Heated windscreen, Soft-close doors, TV, DAB, AMI, Quad Zone, Auto Boot, Auto dim Mirrors, Keyless entry, PDC with rearview camera, AFS II HeadlightsMy DIY jobs - Fan Jet Windscreen Washers, Retrofitted Electric Side Blinds
|
|
#3
15th June 2025, 01:16 PM
|
||||
|
||||
|
Hello Steamship.
Thank you for your reply. I have tried wrestling with the wheel up and down quite forcefully for a bit with no luck. I am unsure if it is the threaded rod that is meant to rotate? As for the VAG diagnostic route is a no go. It found no module for it to talk to?
|
|
#4
Yesterday, 09:31 PM
|
||||
|
||||
|
Ok. I have managed to remove the unit from the dash and oh boy were the corkscrew well and truly stuck. After about 3 hours of wd40 other all in one and lithium grease the fro and back is somewhat loose. But I managed to mangle the rear part of the screw (where a washer and clip reside) to allow me to rotate the screw with the gears disengaged from the motor. So it's kind of working. But it seems to seize again after a few back and fro again. Unless the battery is flat. Anyway I have put the batt to charge and will check again tomorrow. I am hesitating to do the same on the up down. As the screw and gearbox.is even more difficult to access.... how hard is it to replace the whole unit?
__________________
2001 A8 3.7 Hibiscus Red  SLK 200 - 2005 Ford Transit Custom - 2014
|
|
